MAIN APPLICATIONS
Jacking systems
CONTINUOUS SERVICE TEMPERATURE RANGE
-40°F / +212°F
-40°C / +121°C
RECOMMENDED FLUIDS
Mineral oils, vegetable and rape seed oils, glycol and polyglycol
based oils, synthetic ester based oils, oils in aqueous emulsion,
water
TUBE: Oil resistant synthetic rubber
REINFORCEMENT: Two high tensile steel braids
COVER: Environment resistant synthetic rubber
APPLICABLE SPECS: IJ100 hydraulic jack spec.
TYPE APPROVALS: GOST-R
KEY PERFORMANCE
Weight-lifting by means of jacking system • Extreme static pressure • Tested /approved for specific
jacking applications • Test certificate available upon request
|
|
|
|
|
|
|
|
|
|
|
PART REF.
|
HOSE SIZE
|
R.O.D.
|
O.D.
|
MAX W.P.
|
BURST
PRESSURE
|
MIN. BEND
RADIUS
|
WEIGHT
|
MF3000
FITTING
|
MF2000
FITTING
|
|
DN
|
dash
|
inch
|
mm
|
inch
|
mm
|
inch
|
bar
|
psi
|
bar
|
psi
|
mm
|
inch
|
g/m
|
lb/ft
|
|
|
|
J-04
|
6
|
-4
|
1/4"
|
-
|
-
|
14.7
|
0.58
|
725
|
10500
|
1450
|
21025
|
100
|
3.94
|
360
|
24
|
OPB
|
MF+M03400-04
|
|
J-06
|
10
|
-6
|
3/8"
|
-
|
-
|
16.8
|
0.66
|
725
|
10500
|
1450
|
21025
|
127
|
5.00
|
395
|
26
|
OPB
|
MF+M03400-06
|
