MAIN APPLICATIONS
Medium-high pressure hydraulic lines with installation constraints, pilot lines, return, drain, and suction lines
CONTINUOUS SERVICE TEMPERATURE RANGE
-40°F / +212°F
-40°C / +100°C
RECOMMENDED FLUIDS
Mineral oils , vegetable and synthetic ester-based oils
(up to 212°F I 100°C), glycols and polyglycols, mineral oils in aqueous emulsion, water
TUBE: Synthetic rubber
REINFORCEMENT: One wire braid (DN 6+25), Two wire braids (DN 16+25)
COVER: High abrasion resistant synthetic rubber
APPLICABLE SPECS: ISO 18752 Grade A, SAE J517 Type 100 R17, ISO 11237 R17
TYPE APPROVALS: MSHA, GOST-R
KEY PERFORMANCE
Extreme abrasion resistance • Approved at 200.000 impulse cycles, 133% WP at T=100°C (ISO 18752 Grade A) • Very low bend radius to suit restricted space installtions • High robust and compact hose structure compared to rated pressure • High environmental agents resistance • Vacuum resistance according to SAE 100R4 requirements
|
|
|
|
|
|
|
|
|
|
PART REF.
|
HOSE SIZE
|
R.O.D.
|
O.D.
|
MAX W.P.
|
BURST
PRESSURE
|
MIN. BEND
RADIUS
|
WEIGHT
|
MF2000
FITTING
|
|
DN
|
dash
|
inch
|
mm
|
inch
|
mm
|
inch
|
bar
|
psi
|
bar
|
psi
|
mm
|
inch
|
g/m
|
lb/ft
|
|
|
Gl21-03
|
5
|
-3
|
3/16"
|
9.1
|
0.36
|
11.1
|
0.44
|
210
|
3040
|
840
|
12180
|
45
|
1.77
|
170
|
0.11
|
MF+M03300-03
|
|
Gl21-04
|
6
|
-4
|
1/4"
|
10.2
|
0.40
|
12.0
|
0.47
|
210
|
3040
|
840
|
12180
|
50
|
1.97
|
180
|
0.12
|
MF+M03300-04
|
|
Gl21-05
|
8
|
-5
|
5/16"
|
11.5
|
0.45
|
13.6
|
0.54
|
210
|
3040
|
840
|
12180
|
55
|
2.17
|
210
|
0.14
|
MF+M00120-05
|
|
Gl21-06
|
10
|
-6
|
3/8"
|
14.4
|
0.57
|
16.2
|
0.64
|
210
|
3040
|
840
|
12180
|
65
|
2.56
|
300
|
0.20
|
MF+M03300-06
|
|
Gl21-08
|
12
|
-8
|
1/2"
|
17.9
|
0.70
|
19.7
|
0.78
|
210
|
3040
|
840
|
12180
|
90
|
3.54
|
415
|
0.28
|
MF+M03300-08
|
|
Gl21-10
|
16
|
-10
|
5/8"
|
22.2
|
0.87
|
24.0
|
0.94
|
210
|
3040
|
840
|
12180
|
100
|
3.94
|
620
|
0.42
|
MF+M00120-10
|
|
Gl21-12
|
19
|
-12
|
3/4"
|
25.6
|
1.01
|
27.7
|
1.09
|
210
|
3040
|
840
|
12180
|
120
|
4.72
|
780
|
0.52
|
MF+M00120-12
|
|
Gl21-16
|
25
|
-16
|
1"
|
33.0
|
1.30
|
35.2
|
1.39
|
210
|
3040
|
840
|
12180
|
150
|
5.91
|
1120
|
0.75
|
MF+M00120-16
|
|
|
|
