MAIN APPLICATIONS
Hydraulics: suction lines, return lines
Difficult installations with space constraints
CONTINUOUS SERVICE TEMPERATURE RANGE
-40°F / +275°F
-40°C / +135°C
RECOMMENDED FLUIDS
Mineral oils, vegetable and rape seed oils, glycol and polyglycol based oils,
synthetic ester based oils, oils in aqueous emulsion, water
TUBE: NBR synthetic rubber
REINFORCEMENT: High tensile synthetic cord, helix body wire
COVER: Weather and ozone resistant synthetic rubber, flat corrugated cover type
APPLICABLE SPECS: Exceeds SAE J517 100 R4, Manuli® Design; one quarter the SAE J517 100 R4 minimum bend radius
KEY PERFORMANCE
Hardwall hose used for the suction and delivery of hydraulic oils, cooling lines (oils & water glycols) •
Flat corrugated (grooved) cover for improved flexibility and reduced bend radius (1/4 of SAE J517 100 R4) •
Long lasting in severe applications • Resistance to Vacuum • Max. length: 40m
|
|
|
|
|
|
|
|
|
|
|
HF PART
|
PART REF.
|
HOSE SIZE
|
R.O.D.
|
O.D.
|
MAX W.P.
|
BURST
PRESSURE
|
MIN. BEND
RADIUS
|
WEIGHT
|
FITTINGS
|
|
|
DN
|
dash
|
inch
|
mm
|
inch
|
mm
|
inch
|
bar
|
psi
|
bar
|
psi
|
mm
|
inch
|
g/m
|
lb/ft
|
Std1
|
Std2
|
|
EQ1-04-BLUE
|
H01059006*
|
6
|
-4
|
1/4"
|
11.0
|
0.43
|
13.4
|
0.53
|
225
|
3,260
|
1,000
|
14,500
|
100
|
3.94
|
240
|
0.16
|
MF+M00120-04
|
OPF-04
|
|
EQ1-05-BLUE
|
H01059008*
|
8
|
-5
|
5/16"
|
12.6
|
0.50
|
15.0
|
0.59
|
215
|
3,110
|
900
|
13,050
|
114
|
4.49
|
280
|
0.19
|
MF+M00120-05
|
–
|
|
EQ1-06-BLUE
|
H01058010*
|
10
|
-6
|
3/8"
|
15.0
|
0.59
|
17.3
|
0.68
|
180
|
2,610
|
800
|
11,600
|
127
|
5.00
|
335
|
0.23
|
MF+M00120-06
|
–
|
|
EQ1-08-BLUE
|
H01059012*
|
12
|
-8
|
1/2"
|
18.1
|
0.71
|
20.5
|
0.81
|
160
|
2,320
|
680
|
9,860
|
178
|
7.01
|
430
|
0.29
|
MF+M00120-08
|
–
|
|
EQ1-10-BLUE
|
H01059016*
|
16
|
-10
|
5/8"
|
21.3
|
0.84
|
23.5
|
0.93
|
130
|
1,880
|
600
|
8,700
|
200
|
7.87
|
500
|
0.34
|
MF+M00120-10
|
–
|
|
EQ1-12-BLUE
|
H01059019*
|
19
|
-12
|
3/4"
|
25.2
|
0.99
|
27.7
|
1.09
|
105
|
1,520
|
500
|
7,250
|
240
|
9.45
|
640
|
0.43
|
MF+M00120-12
|
–
|
|
EQ1-16-BLUE
|
H01059025*
|
25
|
-16
|
1"
|
33.1
|
1.30
|
35.8
|
1.41
|
88
|
1,270
|
360
|
5,220
|
300
|
11.81
|
970
|
0.65
|
MF+M00130-16
|
–
|
|
EQ1-20-BLUE
|
H01059031*
|
31
|
-20
|
1-1/4"
|
40.6
|
1.60
|
43.5
|
1.71
|
65
|
940
|
345
|
5,000
|
420
|
16.54
|
1,300
|
0.87
|
MF+M00110-20
|
OPK-20
|
|
EQ1-24-BLUE
|
H01059038*
|
38
|
-24
|
1-1/2"
|
46.9
|
1.85
|
50.0
|
1.97
|
50
|
720
|
290
|
4,200
|
500
|
19.69
|
1,540
|
1.03
|
MF+M00110-24
|
OPK-24
|
|
EQ1-32-BLUE
|
H01059051*
|
51
|
-32
|
2"
|
60.4
|
2.38
|
63.1
|
2.48
|
40
|
580
|
250
|
3,620
|
630
|
24.80
|
2,100
|
1.41
|
MF+M00110-32
|
OPK-32
|
|
EQ1-40-BLUE
|
H01059063*
|
63
|
-40
|
2-1/2"
|
72.0
|
2.83
|
74.6
|
2.94
|
35
|
500
|
140
|
2,030
|
600
|
23.62
|
2,400
|
1.61
|
MF+M03400-40
|
–
|
|
|
|
